| Product | Permanent Sintered Neodymium Magnets/Rare Earth Magnet | |
| Material | NdFeB Permanent Magnet | |
| Shape | Disc,Block,Ring,Countersunk,Segment,Trapezoid,Irregular shapes are available,Or Customized Shapes | |
| Size | Customized according to customers’requirements | |
| Coating | NiCuNi,Zinc,Epoxy etc | |
| Density | 7.5-76 g/cm³ | |
| Certification | ISO9001,MSDS,SGS,ROHS,REACH,etc | |
| Applications | 1.Electronic areas:speakers,headphones,acoustics,sensors and so on. | |
| 2.Motor areas:generators,servo motors,micro-motors,vibration motors, elevator motor and so on. | ||
| 3.Clean Tech Energy:Water flow enhancement,wind turbines. | ||
| 4.Health care:MRI,medical treatment equipment. | ||
| 5.Other industries:electric doors and windows,electric vehicle,electric bicycles,computer,phone,boxesmagnetic toos, notebook and so on |
||
Can I customize products？
Yes, Custom Magnets Are Available.
Please tell us the Size, Grade, Surface Coation and Quantity of the magnet, you will get the most reasonable Quotation Quickly.
Here are some regular magnet sizes for reference
1. Custom Size — ( Please noted all size in mm or inch )
– Round Magnet: Diameter x Height
– Ring Magnet: Outer Diameter x Height – Inter Diameter
– Block Magnet: Length x Width x Height
– Special Shape Magnet: Drafts or drawings will be appreciated2. Custom Magnet Shape — ( According to your requirements )
– Disc, Ring, Round, Block, Bar, Countersunk, Triangle, Segment/Tile/Arc, Cylinder, Trapezoid, Fan-shape, irregular shape customize etc3. Grade Choose — ( The higher the performance level, the stronger the magnetism )
– N35, N38, N40, N42, N45, N48, N50, N52 (Max Working Temperature 80°C)
– N35M – N50M (Max Working Temperature 100°C)
– N33H – N52H (Max Working Temperature 120°C)
– N30SH – N50SH (Max Working Temperature 140-150°C)
– N35UH – N48UH (Max Working Temperature 170-180°C)
– N28EH – N42EH, N30AH (Max Working Temperature 200-230°C)4.Surface Coation — ( Zn and Ni-Cu-Ni coating is the most popular coating )
– Zinc, Nickel, Nickel+Copper+Nickel, Gold, Epoxy, Nickel+Epoxy coating
– Round Magnet: Diameter x Height
– Ring Magnet: Outer Diameter x Height – Inter Diameter
– Block Magnet: Length x Width x Height
– Special Shape Magnet: Drafts or drawings will be appreciated2. Custom Magnet Shape — ( According to your requirements )
– Disc, Ring, Round, Block, Bar, Countersunk, Triangle, Segment/Tile/Arc, Cylinder, Trapezoid, Fan-shape, irregular shape customize etc3. Grade Choose — ( The higher the performance level, the stronger the magnetism )
– N35, N38, N40, N42, N45, N48, N50, N52 (Max Working Temperature 80°C)
– N35M – N50M (Max Working Temperature 100°C)
– N33H – N52H (Max Working Temperature 120°C)
– N30SH – N50SH (Max Working Temperature 140-150°C)
– N35UH – N48UH (Max Working Temperature 170-180°C)
– N28EH – N42EH, N30AH (Max Working Temperature 200-230°C)4.Surface Coation — ( Zn and Ni-Cu-Ni coating is the most popular coating )
– Zinc, Nickel, Nickel+Copper+Nickel, Gold, Epoxy, Nickel+Epoxy coating
5. Quantity — ( Samples are available )
– In order to quote the exact competitive price,the quantity for magnet is essential.
Magnet Details
1. Size Tolerance ( +/-0.05mm )
a. Before grinding and cutting, we inspect the black product tolerance.
b. Before and after coating, we will inspect the tolerance by AQL standard.
c. Before delivery, will inspect the tolerance by AQL standard.PS: Product size can be customized.
b. Before and after coating, we will inspect the tolerance by AQL standard.
c. Before delivery, will inspect the tolerance by AQL standard.PS: Product size can be customized.
2. Surface Treatment
Q: Do neodymium magnets require surface treatments?
A: Yes. If magnets are without surface coating (also named plating), it may rust easily under humid conditions.
There have many plating options like Ni-Cu-Ni, Nickel, Zinc, Gold, Black Epoxy, White Epoxy coating and so on.
Zn and Ni-Cu-Ni coating are the most popular coating. The magnet with plating will resist the corrosion effectively.
A: Yes. If magnets are without surface coating (also named plating), it may rust easily under humid conditions.
There have many plating options like Ni-Cu-Ni, Nickel, Zinc, Gold, Black Epoxy, White Epoxy coating and so on.
Zn and Ni-Cu-Ni coating are the most popular coating. The magnet with plating will resist the corrosion effectively.
3. Magnetization Direction:
FAQ
Q1. Can I have a sample order for Neodymium/Ferrite/Rubber magnet or other new magnet?
A: Yes, we accept sample order to test andcheck quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: Sample lead time 3-5 days, bulk order lead time 7-10days.
Q3. Do you have any MOQ for Neodymium/Ferrite/Rubber magnet or other new magnet?
A: Sample MOQ 1pc, bulk order MOQ 100-1000,depends on size and complexity.
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS,FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional. We also accept to ship the products toyour agent.
Q5. How to proceed an order for Neodymium/Ferrite/Rubber magnet or other new magnet?
A: We need to know your requirements or application. And then we will quote the price according to your requirements or our suggestions. Finally after your confirmation the samples and places deposit, we will arrange the production.
Q6. Is it OK to print my logo on magnet product or package?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you test all your goods before delivery?
A:We have quality control before delivery
Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality, fast lead time and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from. We welcome field visits to meet and negotiate.
